EATON 2-POLE 30A BOLT-ON 277V MCCB

A 30 Amp, two-pole Eaton Series C GHB molded case breaker for bolt-on use in 480Y/277 VAC systems. It supports up to 480Y/277 VAC with a 14 kAIC interrupting rating at that voltage (65 kA at 240 V). This thermal-magnetic breaker uses bolt-on connections and has lug terminals for approximately #10 AWG to 1/0 AWG conductors.

Product Specifications

Brand / Manufacturer : Eaton

Type : GHB

Category : Circuit Breaker

Cat. No : GHB2030

Poles : 2-Pole

Amperage (A) : 30

Voltage (V) : 277/480

Connection Type : Bolt-on

Interrupting Current (AIC) : 14,000

Dimensions (Inches) L x W x H : 2.63 in (L) x 2.0 in (W) x 4.0in (H)

Weight (Lbs) : 0.95
