EATON 2-POLE 70A BOLT-ON 277V MCCB

A 70 Amp, two-pole Eaton Type GHB molded case circuit breaker engineered for bolt-on mounting in industrial panelboards (e.g. 277/480 V systems). It has a maximum voltage rating of 480Y/277 VAC with a 14 kAIC interrupt capacity at that voltage (and up to 65 kAIC at 240 V). The breaker’s lugs accommodate feeder cables from approximately #10 AWG up to 1/0 AWG in size.

Product Specifications

Brand / Manufacturer : Eaton

Type : GHB

Category : Circuit Breaker

Cat. No : GHB2070

Poles : 2-Pole

Amperage (A) : 70

Voltage (V) : 277/480

Connection Type : Bolt-on

Interrupting Current (AIC) : 14,000

Dimensions (Inches) L x W x H : 2.63 in (L) x 2.0 in (W) x 4.0in (H)

Weight (Lbs) : 0.95
