EATON 3-POLE 125A 600V MCCB 65KAIC

A 125 Amp, three-pole Eaton Series C molded case circuit breaker (Type HFD, F-frame) for systems up to 600 V AC. It offers a high interrupting capacity of 65 kA at 480 V (and is rated for 25 kA at 600 V) to safely clear large faults. The breaker has a feed-through design with bolt-on mounting and line/load lugs, and it typically accommodates copper or aluminum conductors from #14 AWG up to 1/0 AWG.

Product Specifications

Brand / Manufacturer : Eaton

Type : HFD

Category : Circuit Breaker

Cat. No : HFD3125

Poles : 3-Pole

Amperage (A) : 125

Voltage (V) : 600

Connection Type : Bolt-on

Interrupting Current (AIC) : 100,000 @240V, 65,000 @480V

Dimensions (Inches) : 3.38 (L) x 4.13 (H) x 4.13 (W)

Weight (Oz / Lbs) : 4.25
