EATON 3-POLE 200A MCCB

A 200 Amp, three-pole Eaton Type CC molded case breaker often used as a main or feeder in multi-tenant panels and meter stacks. It’s rated for 120/208Y and 240 V AC applications and carries a 10 kAIC interrupting rating (typically used in systems with upstream protection). This bolt-on breaker includes lugs for large conductors (usually from 2/0 AWG up to 300 kcmil) on the line and load sides.

Product Specifications

Brand / Manufacturer : Eaton

Type : CH

Category : Circuit Breaker

Cat. No : CC3200X

Connection Type : Feed-thru

Poles : 3-Pole

Amperage (A) : 200

Voltage (V) : 240

Connection Type : Feed-thru

Interrupting Current (AIC) : 10,000

Dimensions (Inches) L x W x H : 7.7 in (L) x 4.5 in (W) x 5.4 in (H)

Weight (Lbs) : 2.9
