EATON 3-POLE 20A BOLT-ON 277V MCCB

A 20 Amp, three-pole Eaton Type GHB Series C breaker intended for 480Y/277 V AC systems (such as lighting panelboards). It provides a 14 kA interrupting capacity at 480 V AC and mounts as a bolt-on unit in the panelboard (Eaton G-frame molded case design). The breaker has fixed thermal-magnetic trip and uses a load-side lug for branch wiring, supporting wire sizes approximately #14 to #4 AWG.

Product Specifications

Brand / Manufacturer : Eaton

Type : GHB

Category : Circuit Breaker

Cat. No : GHB3020

Poles : 3-Pole

Amperage (A) : 20

Voltage (V) : 277/480

Interrupting Current (AIC) : 14,000

Dimensions (Inches) L x W x H : 2.63 in (L) x 3 in (W) x 4 in (H)

Weight (Lbs) : 1.75
