EATON 3-POLE 30A BOLT-ON 277V MCCB
Regular price
$389.00
Couldn't load pickup availability
Got questions?
Feel free to get in touch
A 30 Amp, 3-pole molded-case circuit breaker (Eaton Series C Type GHB) built for 480Y/277 V AC systems. It features 14 kA AIC at 480 V AC (65 kA at 240 V), uses a bolt-on mounting system, and supports wiring from #10 to 1/0 AWG.
Product Specifications
Brand / Manufacturer : Eaton
Type : GHB
Category : Circuit Breaker
Cat. No : GHB3030
Poles : 3-Pole
Amperage (A) : 30
Voltage (V) : 277/480
Interrupting Current (AIC) : 14,000
Dimensions (Inches) L x W x H : 2.63 in (L) x 3 in (W) x 4 in (H)
Weight (Lbs) : 1.75
